Lemon Energy

Lemon Punch 24v

Lemon Punch 24v

£1,560.00 GBP
£0.00 GBP £1,560.00 GBP
Sale Sold out
Taxes included.

Lemon Punch is our new 12 and 24v line of batteries. The 24v battery has 310Ah of capacity boasting a whopping 8kWh of usable power in a small package. Weighing in at just 58kg it is close in weight to just 2 110ah AGM leisure battery but outputting 6-8 times the usable power. This powerful package will run a 5kW inverter off just one battery.

Specification

Nominal Voltage: 12.8V
Nominal Capacity: 310Ah @0.5C discharge current 25±2C
Nominal Power: 7.5kWh
Weight: 58Kg
Discharge Cut-off Voltage: (V) 20.8V
Charge Voltage: (V) 28.8V
Recommended Charge/Discharge Current: 150A @25±2C
Max charge/discharge Current: 200A @25±2C
Recommended charge/discharge Current: 150A @25±2C
Max charge/discharge Current: 200A @25±2C
Working Temperature:
0~50℃(Charge)
-10~50℃(Discharge)
-20~55℃(Storage)
SOC Range: 0%- 100%
Recommended SOC: Range 10-100%
Communication Interface: CAN and RS485
Internal CNN Fuse: 250A
IP level: IP 20

Shipping & Returns

In Stock and Available for Next Day Pallet Delivery

Dimensions

Care Instructions

Please read all included documentation and instructions before installation.

Always check product compatibility before powering up.
